- Functional Description
- Specifications
- Applications
1. No dark zone in lighting connected area and mix well
2. Full concealed water-proof with high heat conductivity glue
3. Circuit could be concealed at the back of the light
技術分類Technical?Classification | 項目規格Item | 參數Parameter |
電氣性能Electrical?Properties | 供電電壓Input?voltage | DC24V |
最大功耗Max.power?consumption | 18W/20W | |
光學性能Optical?Properties | 光源組成LED?composition | 60顆/108顆/180顆/216顆LED 60pcs/108pcs/180pcs/216pcs?LED |
顯示像素Pixels | 1像素/米?1pixels/meter | |
光色LED?color | RGB/白光/黃光/藍光 GUB/White/Yellow/Bule | |
光束角Beam?angle | 30°?特殊45°，60°，90° 30°/45°/60°/90°?are?available | |
光通維持率Luminous?maintenance?rate | 50000?hour（@70%） | |
控制方式Control?Mode | 控制接口Interface | DMX512 |
控制系統Control?System | 中鳴科技Easyplay5.0 | |
結構性能Structure | 尺寸(長x寬x高)?Dimension?(L*W*H) | 1000x43x73mm |
重量Weight | 1.3?Kg | |
燈體材料Material | 鋁型材 Aluminium?housing | |
工作溫度Work?temperature | -20℃～50℃ | |
工作濕度Work?humidity | 0～90% | |
儲存溫度?Storage?temperature | -40℃～10℃ | |
使用環境Work?Environment | 干燥/潮濕dry/humid | |
安全性能Safety | 防護等級? Protction?Rating | IP66 |
供電方式 Input?Voltage | 發光顏色LED?Color | 產品編號Model |
DC24V | RGB?PH5?216顆?20W RGB?PH5?216pcs?20W | JZ07-121601-011 |
白光?PH5?180顆?18W White?PH5?180pcs?18W | JZ07-118003-011 | |
黃光?PH5?180顆?18W Yellow?PH5?180pcs?18W | JZ07-118002-011 | |
藍光?PH5?180顆?18W Blue?PH5?180pcs?18W | JZ07-110801-011 | |
白光?食人魚?60顆?18W White?Piranha?LED?60pcs?18W | JZ07-206003-011 | |
黃光??食人魚?60顆?18W Yellow?Piranha?LED?60pcs?18W | JZ07-206001-011 | |
藍光??食人魚?60顆?18W Blue??Piranha?LED?60pcs?18W | JZ07-206002-011 |
-
